Class NavmeshAdd Extends NavmeshClipper

void DrawGizmos ()

void ForceUpdate ()

Forces this navmesh add to update the navmesh.

This update is not instant, it is done the next time it is checked if it needs updating.

Rect GetBounds (

Pathfinding.Util.GraphTransform	inverseTransform
float	radiusMargin

)

Bounds in XZ space after transforming using the *inverse* transform of the inverseTransform parameter.

The transformation will typically transform the vertices to graph space and this is used to figure out which tiles the add intersects.

void GetMesh (

refInt3[]	vbuffer	Assumed to be either null or an array which has a length of zero or a power of two. If this mesh has more vertices than can fit in the buffer then the buffer will be pooled using Pathfinding.Util.ArrayPool.Release and a new sufficiently large buffer will be taken from the pool.
out int[]	tbuffer	This will be set to the internal triangle buffer. You must not modify this array.
Pathfinding.Util.GraphTransform	inverseTransform=null	All vertices will be transformed using the Pathfinding.GraphTransform.InverseTransform method. This is typically used to transform from world space to graph space.

)

Copy the mesh to the vertex and triangle buffers after the vertices have been transformed using the inverse of the inverseTransform parameter.

void RebuildMesh ()

bool RequiresUpdate (

GridLookup<NavmeshClipper>.Root

previousState

)

Returns true if this object has moved so much that it requires an update.

When an update to the navmesh has been done, call NotifyUpdated to be able to get relavant output from this method again.

Vector3? Center

Vector3 center

Mesh mesh

Custom mesh to use.

The contour(s) of the mesh will be extracted. If you get the "max perturbations" error when cutting with this, check the normals on the mesh. They should all point in the same direction. Try flipping them if that does not help.

float meshScale = 1

Vector2 rectangleSize = new Vector2(1, 1)

Size of the rectangle.

MeshType type

float updateDistance = 0.4f

Distance between positions to require an update of the navmesh.

A smaller distance gives better accuracy, but requires more updates when moving the object over time, so it is often slower.

float updateRotationDistance = 10

How many degrees rotation that is required for an update to the navmesh.

Should be between 0 and 180.

bool useRotationAndScale

Includes rotation and scale in calculations.

This is slower since a lot more matrix multiplications are needed but gives more flexibility.

Color GizmoColor = new Color(154.0f/255, 35.0f/255, 239.0f/255)

Int3[] gizmoBuffer

MeshType

void AddEnableCallback (

System.Action<NavmeshClipper>	onEnable
System.Action<NavmeshClipper>	onDisable

)

void RemoveEnableCallback (

System.Action<NavmeshClipper>	onEnable
System.Action<NavmeshClipper>	onDisable

)

List<NavmeshClipper> allEnabled

All navmesh clipper components in the scene.

Not ordered in any particular way.

GraphMask graphMask = GraphMask.everything

Which graphs that are affected by this component.

You can use this to make a graph ignore a particular navmesh cut altogether.

Note that navmesh cuts can only affect navmesh/recast graphs.

If you change this field during runtime you must disable the component and enable it again for the changes to be detected.

void Awake ()

void NotifyUpdated (

GridLookup<NavmeshClipper>.Root

previousState

)

Internal method to notify the NavmeshAdd that it has just been used to update the navmesh.

void OnDisable ()

void OnEnable ()

void OnUpgradeSerializedData (

refMigrations	migrations
bool	unityThread

)

Handle serialization backwards compatibility.

void Reset ()

Handle serialization backwards compatibility.

void UpgradeSerializedData (

bool

isUnityThread

)

Transform tr

cached transform component

int[] tris

Cached triangles.

Vector3[] verts

Cached vertices.
